PrimaX
GB
49
Special Conditions for Safe Use
- Do not open the instrument when energised.
- For dust applications the installation conditions according to EN 61241-14 has
to be considered.
- Intensive electrostatic charging processes have to be prevented on the instru-
ment label.
- Maintenance or repairment according to the type of protection "d" is only al-
lowed by the manufacturer
Cable gland
- M25 x 1,5;Torque 8 -12 Nm; only ATEX certified versions for gas and dust shall
be used.
- NPT ¾"- 14; fixture with 2 layer PTFE sealing tape or according to the instruc-
tions of the NPT supplier; when removed, new PTFE sealing has to be used af-
ter reinstalling; only ATEX certified versions for gas and dust shall be used.
EMC Conformance according to the Directive 2004 / 108 / EC
EN 50270:2006 Type 2, EN 61000-6-3:2007
Prima X
Ox/Tox sensor
Ex d ia IIC T4 Gb
Ex tb ia IIIC T130°C Db IP 67
-40°C Ta +70°C
Option: HART Module Connector, only for temporary connection of an
intrinsic safe HART Field Communicator
P
o
200 mW, U
o
2,7 V, I
0
140 mA, L
o
10 µH, C
o
1nF
P
i
5mW, U
i
5 V, I
i
1mA, L
i
= 0, C
i
= 0
Relais: switching voltage = 30 VDC; switching current = 2 ADC
EC-Type Examination Certificate: BVS 10 ATEX E009 X
Quality Assurance Notification: 0158
Year of Manufacture: see Label
Serial Nr.: see Label
