AppendixMSA
PrimaX
GB
77
PEPPERL+FUCHS
KFD2
- STC4 - Ex1
Controller
Suprema
GasGard XL
9010/20
+ 1
- 2
+ 1
-
3
+ 8
-
7
+ 14 - 15
24V DC
+24V
0 V
R
Cable
max = 200 Ω
4 – 20mA
MTL
MTL 5541/S
Controller
Suprema
GasGard XL
9010/20
+ 1
- 2
+ 2
-
1
+ 12
-
11
+ 14 - 13
24V DC
+24V
0 V
R
Cable
max = 200 Ω
4 – 20mA
STAHL
9160/13 -
11 -
11
Controller
Suprema
GasGard XL
9010/20
+ 1
- 2
+ 12
- 10
+ 1
-
2
+ 7 - 9
24V DC
+24V
0 V
R
Cable
max = 220 Ω
4 – 20mA
STAHL
9160/13 -
10 -
11
Controller
Suprema
GasGard XL
9010/20
+ 1
- 2
+ 12
- 10
+ 1
-
2
+24V
-
4 - 20mA
R
Cable
max = 220 Ω
-
+ 7 - 9
24V DC
