MSA ULTIMA X5000 User Manual

Figure 39 Horn Mode Relay Map and Alarm Actuation
AnalogOutputSettingsforFaultConditions
Analogoutputscanbesetto3.5mAand1.25mAwithHART,ortocustomoutputvaluesaslistedinTable13.Output
settingsforoxygensensorsarenotconfigurable.TheMaintenanceanalogoutputisusedduringstartup,ResetMainUnit,
andControllerDataReset.
TochangeAnalogoutputssettings:
1. ScrolltoSettings.
2. SelectInstruments.
3. ScrollandSelectAnalogSettings.
4. Select3.5,1.25,Custom1orCustom2.
5. SelectSave.
6. (OnlyCustom)SelectFault,Calibration,orMaintenance.
7. (OnlyCustom)Enterdesiredoutputlevels(optionsinTable13).
8. (OnlyCustom)SelectSave.
9. (OnlyCustom)Repeatforremainingoutputs.
10.SelectSave.
Table 13 Analog Output Setting Options
Output
Setting(mA)
3.5mA 1.25mA
Custom1
Default
1
Custom2
Default
FaultRelayAction
AORangeOptions
Fault 3.5
2
1.25
2
2.0 2.0 Open,Latching Range:0.000-3.750
Increment:0.025
Calibration
(excl.O
2
)
3.5
2
1.5
2
3.0 3.0 Closed,NoAction Range:0.000-
3.750Increment:
0.025
Cleaning
Mode(NOT
ENABLED)
3.5
2
2.0
2
2.5 2.5 Closed,NoAction Range:0.000-
3.750Increment:
0.025
Maintenance 3.5
2
3.5
2
3.5 3.5 Closed,NoAction Range:0.000-
3.750Increment:
39 Ultima X5000 Gas Monitor US
4 Operation

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
