MSA ULTIMA X5000 User Manual

Gas
(Code)
Thread
Type
4
TruCal
Range
Default
Display
Resolution
3
Unit
Default
Alarm
1
Default
Alarm
1
Default
AO
(mA)
Alarm
2
Default
Alarm
2
Default
AO
(mA)
Alarm
Action
Default
Span
Value
Default
Alarm
Min
Alarm
Max
Range
Min
Range
Max
Span
Value
Min
Span
Value
Max
Hydrogen
Sulfide
(27,86
Fine
0-10.0
PPM
0.1 PPM 1.0 5.6 3.0 8.8
Increasing
Non-Latch
5.0 1.0 100 0-10 0-100 5
FS
1
Hydrogen
Sulfide
(28,87)
Fine
0-50.0
PPM
0.1 PPM 5.0 5.6 15.0 8.8
Increasing
Non-Latch
40.0 1.0 100 0-10 0-100 5
FS
1
Hydrogen
Sulfide
(29,88)
Fine
0-100
PPM
0.1 PPM 10.0 5.6 30.0 8.8
Increasing
Non-Latch
40.0 1.0 100 0-10 0-100 5
FS
1
Nitric
Oxide
(72)
Fine
0-100
PPM
0.5 PPM 10 5.6 20 7.2
Increasing
Non-Latch
50 5 100 0-2.5 0-100 1 FS
1
Nitrogen
Dioxide
(73)
Coarse
0-10
PPM
0.1 PPM 1 5.6 2 7.2
Increasing
Non-Latch
5 0.5 10 0-1.5 0-10 1.5 FS
1
Oxygen
FM(15)
Fine 0-25% 0.1 % 19.5 16.48 18.0 15.5
Decreasing
Non-Latch
20.8 17 24 5-25 15  
Oxygen
(16)
Fine 0-25% 0.1 % 19.5 16.48 18.0 15.5
Decreasing
Non-Latch
20.8 5.0 25.0 5.0-25 5.0-25 15 25
Low
Oxygen
(17)
Fine 0-25% 0.1 % 1 4.64 2 5.28
Increasing
Non-Latch
20.8 0.2 25 0-2 0-25
20.8
(Room
Air)
FS
1
Sulfur
Dioxide
(50)
Coarse
0-25
PPM
0.1 PPM 2.0 5.28 5.0 7.2
Increasing
Non-Latch
10 0.4 25 0-5.0 0-25 2.5 25
4 Operation
ULTIMA® X5000 54

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
