MSA ULTIMA X5000 User Manual

Table 15 Default Sensor Settings - XIR Plus Sensors
Gas(Code)
Range
Default
Display
Resolution
1
Unit
Default
Alarm1
Default
Alarm1
Default
AO
(mA)
Alarm2
Default
Alarm2
Default
AO
(mA)
AlarmAction
Default
Span
Value
Default
Alarm
Min
Alarm
Max
Range
Min
Range
Max
Span
Value
Min
Span
Value
Max
XIRPLUS5%
Methane(AA)
0-100 1 %LEL 10 5.6 20 7.2
IncreasingNon-
Latch
50 5 60 0-20 0-100 1 100
XIR
PLUS4.4%
Methane(AC)
0-100 1 %LEL 10 5.6 20 7.2
IncreasingNon-
Latch
57 5 60 0-20 0-100 1 100
XIR
PLUS2.1%
Propane(AB)
0-100 1 %LEL 10 5.6 20 7.2
IncreasingNon-
Latch
29 5 60 0-20 0-100 1 100
XIR
PLUS1.7%
Propane(AD)
0-100 1 %LEL 10 5.6 20 7.2
IncreasingNon-
Latch
35 5 60 0-20 0-100 1 100
XIRPLUS0-
2.00%CO
2

(AF)
0-2.00 0.02 % 0.20 5.6 0.40 7.2
IncreasingNon-
Latch
1.50 0.20 2.00 0-0.40 0-2.00 0.02 2.00
XIRPLUS0-
5.00%CO
2

(AG)
0-5.00 0.05 % 0.50 5.6 1.00 7.2
IncreasingNon-
Latch
2.50 0.50 5.00 0-1.00 0-5.00 0.05 5.00
XIRPLUS0-
100%
LELEthanol
(BY)
0-100 1 %LEL 10 5.6 20 7.2
IncreasingNon-
Latch
35 5 60 0-20 0-100 1 100
XIRPLUS0-
100%
LELEthanol
(CF)
0-100 1 %LEL 10 5.6 20 7.2
IncreasingNon-
Latch
65 5 60 0-20 0-100 1 100
4 Operation
ULTIMA® X5000 56

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
