USER MANUAL V1.0 | Updated January 19, 2019 8
From the main screen of machine, use arrow keys to move the cursor to the desired
object. Press Enter to save and apply settings. Otherwise, press ESC.
Message
Select kind of font you need to use on
messages. Support two kind of font:
Uppercase font and Normal font.
Select size of messages: support up to
5 sizes.
Insert menu (Symbol, Logo,
Counter, Date, Expired, Time,
String, Barcode and Shiftcode)
Insert additional information into
your messages.
Use the existing messages on the
machine memory for printing.
Edit the existing message.
Delete existing messages.
Show all information needed to
monitor your printing process.
Operation
Start or Stop printing job. Combine and press CTRL +
SHIFT + ENTER on keyboard to fast Start / Stop print.
All of nozzle on cartridge will push out ink. After purged
you will see 2 lines of ink on substrate.
Connect PC / Disconnect PC
Connect or Disconnect machine from PC.
Please stop print first, before go to Connect PC menu.
Settings
Set print speed for the machine or select to enable encoder
Set your desired resolution
Set optical density of the print
Set the distance from when the sensor receives signal to the start of
printing or the delay distance after printer accepts a print command
Display the current level of ink in the cartridge or what kind of
current cartridge is plugged to machine
Update logo from USB to the machine memory
Set the chain of data to insert into the print
