MSSC Smart-Jet Plus - Machine Operation Menu; Main Menu and Submenu Navigation

USER MANUAL V1.0 | Updated January 19, 2019 7
ITEMS
DETAIL
[1] USB FLASH
USB 2.0 flash for updating firmware, fonts and logo
[2] USB KEYBOARD
For USB 2.0 wireless keyboard receiver
[3] USB PC
For PC connection with USB 2.0 cable A-B
[4] DB15 EXTENDED
Extend port for external sensor, encoder, alarm, etc…
[5] 12VDC
Power supply
Keyboard
NO
KEY
USE
1
Enter
Confirm, save or apply
2
ESC
Go to previous session
3
/
Move your cursor to left/right
4
/
Move your cursor up/down
5
Shift
Press and hold “Shift” to input capitalized characters
6
Insert
Press “Insert” to insert Symbol, Logo, Counter, Date, Expired,
Time, String, Barcode and Shiftcode into the message
7
Backspace
Delete your message from the left
8
Tab
Move your cursor faster
9
Home/End
Move your cursor to Home/End
10
Caps lock
Uppercase font
11
F4
Insert suomi symbol
Operation menu on machine
Main Menu
Message
Operation
Settings
Open
Create
new
Information
Purge
Start/
Stop
Connect
PC
Speed
Resolution
Density
Use
Select
font
Select size
Delay
Cartridge
Update Logo
Edit
Insert Menu
(Popup menu when press
Insert)
String
Random Jet
Print Side
Delete
Symbol
Logo
Sensor
Direction
Print Mode
Counter
Date
Unit
WiFi
Update Font
Expired
Time
Rollover
System clock
Rotate
String
Barcode
Password
Default
Language
Shiftcode
Custom string
IO signals
Custom string
Coder name
RS485
LCD BackLight
Reset
Bi-directional
Set up backup
About
