MTS Systems FlexTest IIm User Manual

FlexTest IIm Controllers
MTS 793 Controller Hardware Introduction
35
Interlock logic level Inputs 0 = 0 V DC
1 = 3.2 to 24 V DC
Dimensions
Height
Width
Depth
8.9 cm (3.5 in)
48.3 cm (19 in)
54.6 cm (21.5 in)
Model 498.22 Chassis Specifications (part 1 of 2)
P
ARAMETER SPECIFICATION
Dimensions
Height
Width
Depth
40 cm (15.75 in)
48.3 cm (19 in)
55.9 cm (22 in)
Weight 18 kg (40 lb) plus 0.5 kg (1 lb) per
module
Rack mounting requirements:
Clearance-each side
Clearance-back
Clearance-top/bottom
5.7 cm (2.25 in) for air flow
15.3 cm (6.0 in) for cabling
No restrictions
Number of slots 12 VMEbus slots
Power requirements 100 - 120 V AC at 12 A between 50 - 60
Hz
220 - 240 V AC at 6 A between 50 - 60
Hz
Model 497.05 Specifications (part 2 of 2)
P
ARAMETER SPECIFICATION
