Installing the 493.10 Chassis (FTGT)
MTS 793 Controller Hardware Installation
45
493.47 Encoder Processes the signals from an encoder or a Temposonics III
transducer with an SSI interface.
493.48 Acceleration Conditioner Processes the signals from an accelerometer. Each
Acceleration Conditioner mezzanine card can support up to
three accelerometers. Before installing this board, specific
jumpers must be set on the I/O Carrier module. See “I/O
Carrier jumper settings” on page 108 for more information on
jumper settings.
I/O Carrier mezzanine cards (part 2 of 2)
M
ODEL MODULE NAME FUNCTION
ADDA II mezzanine cards
M
ODEL MODULE NAME FUNCTION
493.55 A/D Converts up to eight external analog signals to digital signals
for use by the controller. This board requires the optional
ADDA II module.
493.56 D/A Converts up to eight internal digital signals to analog signals
for use by external devices. This board requires the optional
ADDA II module.
493.57 DSPAD Converts up to eight external analog signals to digital signals
for use by the controller. A DSP chip provides digital filtering.
This board requires the optional ADDA II module.
493.59 Universal Encoder Processes the signals from incremental, absolute, and
Temposonics III encoders. This board requires the optional
ADDA II module.
