Installing the Handle Kit
The Controller may be equipped with an optional handle kit.
The following procedure provides assembly and installation
instructions for the handle kit (MTS PN 100-061-494). The following
table and figure show the handle kit assembly components described
in the procedure.
Handle Kit Parts
I
TEM DESCRIPTION QUANTITY
1 Support arm 2
2 Handle side leg 2
3 Clip 2
4 Washer 4
5 Screw 2
6 Spring 2
7 Button 2
8 Ratchet 2
9 Ratchet housing 2
10 Lock washer 2
11 Handle screw 2
12 Handle 1
13 Cover 2
