MTS 793 Controller Hardware
Installing the 493.10 Chassis (FTGT)
Installation
44
Front Panel VMEbus Modules
M
ODEL MODULE NAME FUNCTION
493.40 I/O Carrier Supports up to four mezzanine cards.
493.43 Multi-Box I/O
The optional module allows multiple controllers to
share a master hardware synchronization clock and pass
station interlock state information between each other.
493.50 ADDA II This optional module supports up to four 8-channel A/D
(Model 493.55) or D/A (Model 493.56) mezzanine cards. This
module also supports the 8-channel DSPAD, 8-channel Delta-
Sigma A/D, and 4-channel Universal Encoder mezzanine
cards.
498.96-X Processor Provides an interface between the controller and an external
computer. The processor module also manages the plug-in
modules and transition panels.
498.71B GRES III Interfaces with a Remote Station Control (RSC) module and
temperature controllers.
I/O Carrier mezzanine cards (part 1 of 2)
M
ODEL MODULE NAME FUNCTION
493.14 Valve Driver Produces the control signal for a Series 252 Servovalve.
493.15 3–Stage Valve Driver Produces the control signal for a Series 256 or 257
Servovalve.
493.21B Universal Conditioner Processes the signals from either an AC or DC-type sensors.
493.25 Universal Conditioner Processes the signals from either an AC or DC-type sensors.
493.45 A/D Converts up to six external analog signals to digital signals for
use by the controller.
493.46 D/A Converts up to six internal digital signals to analog signals for
use by external devices.
