7.17 Belt Drive
7.17.1 Drive belt – Condition check
Preconditions
☑Engine is stopped and starting disabled.
☑Guard is removed.
Drive belt – Condition check
Item Findings Action
Drive belt A Singular cracks None
Drive belt B Cracks on entire circumference Replace (→ Page 130)
Drive belt C Chunking
Drive belt Belt is oily, shows signs of over-
heating
M015655/05E 2015-06 | Task Description | 129
TIM-ID: 0000000920 - 011
