3.4 Engine – Main dimensions
Main dimensions
Engine model Length (A) Width (B)
Height (C)
12V2000M93 approx. 2069 mm approx. 1295 mm approx. 1350 mm
16V2000M93 approx. 2486 mm approx. 1295 mm approx. 1390 mm
52 | Technical Data | M015655/05E 2015-06
TIM-ID: 0000050222 - 002
