MTU 12V2000M93 - Shield A4; Shield A5; Shield A7; Shield A8

Item Type of shielding Comments
1 (free end) Shield (A8) On fuel filter
2 (free end) Shield (A7) Above fuel priming pump
3 (free end) Shield (A7) Below fuel priming pump
Driving end A-side
Item Type of shielding Comments
1 (Driving end, A-side) Shield (A5) On air flap
2 (driving end, A-side) Shield (A4) On brazed-on union
3 (driving end, A-side) Shield (A5) On turbocharger flap
4 (driving end, A-side) Shield (A5) On turbocharger flap
Driving end A-side
M015655/05E 2015-06 | Task Description | 75
TIM-ID: 0000010064 - 006
