2. Mechanical description
2.1 Overview
2.1.1 Models with 5-way plug-in 5.00mm pitch terminal block
The pictures below show the mechanical design of the unit along with the positions of the different
connectors and mounting holes. The device case is made of durable PC/ABS plastic.
