3.1.8 1-Wire
ABSOLUTE MAXIMUM RATINGS
Symbol
Parameter
Conditions
Min.
Max.
Unit
V
I
Input voltage
-0.5
6
V
Transient pulse
-100
100
V
CHARACTERISTICS
Symbol
Parameter
Conditions
Min.
Typ.
Max.
Unit
V
IH1
Input High
1.9
V
V
IL1
Input Low
0.9
V
R
WPU
Weak pullup resistor
1000
1675
Ω
V
OL1
Output Low
At 4mA load
0.4
V
3.1.9 Power Relay
CHARACTERISTICS
Symbol
Parameter
Conditions
Min.
Typ.
Max.
Unit
Contact rating
DC
6
30
A
V
AC
6
250
A
V
R
C
Contact resistance
At 1A 6VDC
100
mΩ
I
SW
Switching current
6
A
V
SW
Switching voltage
DC
125
V
AC
400
V
Electrical endurance
Resistive load, at 85ºC, 1s on 9s off, 6A
250VAC
3x10
4
cycles
Mechanical endurance
10
7
cycles
R
I
Insulation resistance
At 500VDC
1000
MΩ
3.1.10 Latch Relay
CHARACTERISTICS
Symbol
Parameter
Conditions
Min.
Typ.
Max.
Unit
Contact rating
DC
1
30
A
V
AC
0.5
125
A
V
R
C
Contact resistance
At 10mA 30mVDC
100
mΩ
I
SW
Switching current
2
A
V
SW
Switching voltage
DC
110
V
AC
125
V
Electrical endurance
Resistive load, at 70ºC, 1s on 9s off,
0.5A 125VAC
10
5
cycles
Mechanical endurance
10
8
cycles
R
I
Insulation resistance
At 500VDC
1000
MΩ
