MTX MTX-3G-JAVA-IoT - 2.1.2 Models with 7-way Plug-in 3.50 mm Pitch Terminal Block

MTX-xG-JAVA-IoT Family
www.mtxm2m.com 2017/07 v1.2 Page 35/105
MTX M2M® by MATRIX ELECTRONICA S.L.U
2.1.3 Models with RJ11 connector
The pictures below show the mechanical design of the unit along with the positions of the different
connectors and mounting holes. The modem case is made of durable PC/ABS plastic.
Tri-color Led Indicator
SIM Card Reader, DIP
switches & batt jumper
DB15 connector
DB9 connector
GSM Antenna Connector
Mini USB 2.0 Connector
Mounting holes
Power Supply & Audio Connectors
