4.4.3 Analog inputs
The STD and DB15 models have two independent, unbalanced and multiplexed analog inputs which
can be configured in 0-50V mode. Please read section 4.7 to learn how to setup the mode of the analog
input (current or voltage).
Both ADC inputs have a resolution of 10 bits, which means that the default resolution is 48.8mV (0-
50V). The A/D converter uses the successive approximation conversion technique.
The maximum A/D conversion rate is 5 samples per second.
To know how to read the analog inputs values please read the MTX-IoT Family Software Manual
