1.7 Main features and services
The MTX-IoT performs a set of telecom services (TS) according to GSM standard phase 2+, ETSI and
ITU-T. The services and functions of the MTX-3G-JAVA are implemented by issuing customized
applications embedded on the device, by AT commands issued internally or over the USB, RS232 or
RS485 interface.
1.7.1 Key features at a glance
The MTX-3G-JAVA is a UMTS/HSPA and also GSM/GPRS/EDGE bands mobile station with the
characteristics shown in the table below.
UMTS/HSPA+: Five band, 800/850/900/1900/2100MHz
GSM/GPRS/EDGE: Quad band, 850/900/1800/1900MHz
Class 4 (+33dBm ±2dB) for EGSM850
Class 4 (+33dBm ±2dB) for EGSM900
Class 1 (+30dBm ±2dB) for GSM1800
Class 1 (+30dBm ±2dB) for GSM1900
Class E2 (+27dBm ± 3dB) for GSM 850 8-PSK
Class E2 (+27dBm ± 3dB) for GSM 900 8-PSK
Class E2 (+27dBm +3dB/-4dB) for GSM 1800 8-PSK
Class E2 (+27dBm +3/-4dB) for GSM 1900 8-PSK
Class E2 (+26dBm +3/-4dB) for GSM 1800 8-PSK
Class 3 (+24dBm +1/-3dB) for UMTS 2100, WCDMA FDD BdI
Class 3 (+24dBm +1/-3dB) for UMTS 1900, WCDMA FDD BdII
Class 3 (+24dBm +1/-3dB) for UMTS 900, WCDMA FDD BdVIII
Class 3 (+24dBm +1/-3dB) for UMTS 850, WCDMA FDD BdV
Class 3 (+24dBm +1/-3dB) for UMTS 800, WCDMA FDD BdVI
Single supply voltage
Maximum: 6.5 to 40V (without damaging the device)*
Recommended: 7 to 35V
*(Device operation from 6.5 to 7V is not guaranteed over the whole temperature range / Supplies from 35 to 40V
may damage the device during an extended use)
Dimensions: 78,1 x 66,8 x 37,2 mm Weight: approx. 190g
All hardware components are fully compliant with the EU RoHS Directive
DL 7.2Mbps, UL 5.7Mbps
HSDPA Cat.8 / HSUPA Cat.6 data rates
Compressed mode (CM) supported according to 3GPP TS25.212
PS data rate – 384 kbps DL / 384 kbps UL
CS data rate – 64kbps DL / 64 kbps UL
