MTX-xG-JAVA-IoT Family
www.mtxm2m.com 2017/07 v1.2 Page 53/105
MTX M2M® by MATRIX ELECTRONICA S.L.U
Features (when connected to ASC0)
Includes the data lines TD0 and RD0, the status lines RTS0 and CTS0 and also the modem
control lines DTR0, DSR0 and DCD0.
This port is primarily designed for controlling voice calls, transferring CSD, fax and GPRS data
and for controlling the GSM engine with AT commands.
Full Multiplex capability allows the interface to be partitioned into three virtual channels, but
with CSD and fax services only available on the first logical channel.
The DTR0 signal will only be polled once per second from the internal firmware of MTX-IoT.
The default configuration is 8 data bits, no parity and 1 stop bit. The setting can be changed
using the AT command AT+ICF and, if required, AT^STPB.
Can be operated at fixed bit rates from 1200bps to 921600bps.
Autobauding supports bit rates from 1.2kbps to 460.8kbps.
The default serial speed for MTX-IoT is 115200bps.
Features (when connected to ASC1)
Includes data lines TD0 and RD0 (2-wire/4-wire)
Includes the status lines RTS0 and CTS0 and supports hardware flow control (4-wire only)
Configured for 8 data bits, no parity and 1 or 2 stop bits.
Can be operated at fixed bit rates from 1200 bps to 921600 bps. Autobauding is not supported
on ASC1.
The default serial speed for MTX-IoT is 115200bps.
Pin
Signal
Direction
Description
1
DCD 0
Output
Data carrier detected
2
RD 0
Output
Received data
3
TD 0
Input
Transmitted data
4
DTR 0
Input
Data terminal ready
5
GND
-
Ground connection
6
DSR 0
Output
Data set ready
7
RTS 0
Input
Request to send
8
CTS 0
Output
Clear to send
9
VEXT
Output
Output voltage reference (4V)
