Operating job computer on the field
Controlling the application
6
Reduces the target rate by 10%.
Increases the target rate by 10%.
Switches between automatic and manual target rate regulation.
▪ Automatic: The entered target rate from the “Target Rate” parameter is
used. [➙ 26]
▪ Manual: You are working without a pre-set target rate.
Switches between automatic and manual sequence.
1. - Switch to automatic target rate control.
⇨ The following icon appears in Area 1:
2.
, or - Change the target rate.
⇨ In Area 1, the change and then the new target rate is shown:
→ →
⇨ The job computer regulates the application according to the new target rate.
Operating section valves
This is how you reach the screen with this function:
> ( )
Use the following function keys to operate the function:
Opens all of the section valves of the first section group.
Opens all of the section valves of the second section group.
Closes all of the section valves on the outer left side.
