Mounting and installation
Installing the job computer
4
Mounting and installation
Installing the job computer
Selecting the installation site
Take note of the following when selecting the installation location:
The job computer must be installed on the slurry tanker, not on the tractor.
▪ The job computer should be installed where it is protected from dust and water.
▪ To avoid damage due to the penetration of water, the connections on the job computer must be
pointing to the sides.
Connecting the AMP connectors
This is how to connect two AMP connectors:
1. Pull out the red locking device of the AMP socket all the way to the end.
⇨ You will hear a loud clicking sound.
⇨ The openings for inserting the locking pins of the connector are visible.
2. Insert the connector into the socket. It should be possible to easily insert the locking pins in the
openings.
⇨ The connector is loosely inserted in the socket.
3. Press in the red locking device.
⇨ You will hear a loud clicking sound.
⇨ A part of the locking device comes through to the other side of the socket.
⇨ You have connected and locked the connector with the socket.
Separating the AMP connectors
This is how to separate two AMP connectors:
