7
Configuring the job computer for work
Entering the geometry
Configuring the job computer for work
Before you start working, you must configure the job computer for the work. You must perform the
configuration of the job computer on the “SETTINGS” screen.
Note that depending on the model of the slurry tanker, not all of the parameters can be configured.
To reach the “SETTINGS” screen:
1. On the work screen, press:
⇨ The “SETTINGS” screen appears.
⇨ You can see parameters and function icons for the configuration.
2. If the desired parameters or function icons cannot be seen directly, press
to scroll
to the next page.
⇨ You can perform the configuration.
Entering the geometry
The geometry of an agricultural implement is defined as a series of parameters describing its
dimensions.
The geometry is important particularly for all systems that are GPS-controlled.
The distances you enter depend on whether the implement is towed, mounted on the tractor or self-
propelled.
1. On the work screen, press:
> ( ) >
⇨ The “GEOMETRY” screen appears.
⇨ On the screen, you can see which measurements need to be taken and where they can be
entered.
2. Enter the measured values. With mounted implements that have a boom that is not straight, but
rather curved towards the front, you must enter the values for the individual sections. With
and
, you can switch between the sections.
3.
- Optionally, you can change the name of the mounted implement.
4.
- Optionally, you can call up the “GEOMETRY / Section-Control” screen.
5. Configure the parameters
⇨ You have configured the geometry.
