Maintenance
Change the air de-oiling element
70 13.05.2014
¾ Insert a new air de-oiling element.
¾ Place the screw plug, together with the spring, onto the air de-
oiling element pipe and tighten it. Turn this screw clockwise.
– The arrow on the air de-oiling element points downwards.
7.7 Change chamber lid gasket
¾ Open the chamber lid.
¾ Remove the chamber lid gasket from the groove.
¾ Press the new chamber lid gasket into the groove of the chamber
lid.
– The beginning and end of the chamber lid gasket must butt up
against each other without a gap.
