Maintenance
Change the oil in the vacuum pump
13.05.2014 69
¾ Insert the screw plug with the sealing ring in the fill opening and
screw it tight.
¾ Hold the housing and take the supporting rod out of the holder.
¾ Close the housing.
¾ Tighten the screws on both sides.
– The housing is closed and tight.
¾ Connect the machine to the mains electricity.
¾ Switch on the machine.
¾ Check the oil level after a couple of machine cycles.
7.6 Change the air de-oiling element
¾ Switch off the machine.
¾ Disconnect the machine from the mains electricity.
¾ Remove the screw plug.
¾ Pull out the air de-oiling element.
