© Munters AB, 2020 101
10.7
Expansion Specifications
Parameter Specifications
Input Power Voltage 115/230 VAC, 50/60 Hz
Input AC Power 0.2A
Maximum number of relays
operating simultaneously
10
Note: Running relays at the above current levels provides between 50,000 –
100,000 switching operations.
Communication RS-485: 115 Kbps, 8 bit, even parity
Operating Temperature
Range
-10° to +50° C (+14° to +125° F)
Storage Temperature Range -20° to +80° C (-4° to +176° F)
Environmental
Specifications
Altitude: -400 m to 2000 m
Relative Humidity: 20% - 90%
Main supply voltage fluctuation up to +10 - 20%
Overvoltage category II
Enclosure
Water and dust tight
Indoor use only
Dimensions (H/W/D) 403 x 324 x 141 mm/16 x 13 x 5.6 inches
Fuses Fuse F2 on PS card: 3.15A, 250V
Certification
•
Disconnection device/overcurrent protection: In the building installation, use a
certified 2-pole circuit breaker rated 10A, certified in accordance with the IEC
standard 60947-2 (in the US and Canada use a Listed Brach Circuit protective
circuit breaker). This step is required to provide overcurrent protection and mains
disconnection. The circuit breaker must be easily accessible and marked as the
controller disconnect device.
•
Main Supply Voltage: Permanently connect the controller to the mains in
accordance with the relevant national code. Provide fixed wiring inside a flexible
conduit. Relays must be suitably protected against overcurrent, using a circuit
breaker rated at 10A.
