Muratec MFX-C2700 Configuration Guide

Appendix A - menu system > 100
Fax Setup
a
(cont.)
Fcode Box
Register Confidential Box
Box Name
Sub-Address
Hold Time
I.D.Code
user defined
user defined
00 ~ 0 ~ 31
user defined
Confidential Box:
received data cannot be
printed without entering
ID code (for secret
documents).
You can also enter a
Box Name, Password
and specify the hold
time for your secure
box.
Range: 00 - 31
Bulletin Box
Box Name
Sub-Address
user defined
user defined
Bulletin Box: Enable to
transmit/receive
documents to/from
Bulletin.
Edit Edit settings. Refer to options above for details.
Delete Yes, No Delete entry.
Security
Function
ID Check Tx ON, OFF Check and match the
last four digits of the
destination fax numbers
with those registered in
the target. If ON, the
MFP will send only when
they match.
Broadcast
Destination
ON, OFF Fax number
confirmation screen
displays before sending
the fax.
Confirm Dial ON, OFF When ON, you will be
asked to re-enter the
destination fax number.
The fax will only be sent
when the two numbers
match.
Other
Settings
Redial Tries 0 ~ 2 ~ 9 time(s) Set the number of redial
attempts.
Range: 0 - 9 time(s)
Redial Interval 1 ~ 5 minute(s) Set the time between
redial attempts.
Range: 1 - 5 minute(s)
Ring Response 1 Ring, 5 seconds,
10 seconds, 15 seconds,
20 seconds
Enter the number of
rings required before
receiving an incoming
fax.
Dialling Pause
Duration
0 ~ 2 ~ 10 second(s) Enter the pause
duration required.
Range: 0 - 10 second(s)
Rx Reduc. Rate Auto, 100% Select the Rx reduction
rate.
Reduc. Margin 0 ~ 24 ~ 100 mm Select the reduction
margin.
Range: 0 - 100 mm
ITEM OPTION VALUE/DESCRIPTION
