Section 40 00-02-0716
2013-06-03 - 8 -
NOTE: (S7, 38 & 40) are the S-Numbers used to set the controller for a
mechanical engine. See the S number section of this manual for details.
4. Press the [Up Arrow] and [Down Arrow] until (S38) ENGINE TYPE is displayed, press [Enter]
to highlight the current setting.
5. Press the [Up Arrow] and [Down Arrow] until MECHANICAL is displayed, press [Enter] to un-
highlight the new setting.
6. Press the [Up Arrow] and [Down Arrow] until (S40) ENG THR TYPE is displayed, press
[Enter] to highlight the current setting.
7. Press the [Up Arrow] and [Down Arrow] until MECHANICAL is highlighted then press [Enter]
to un-highlight the new setting.
8. Press the [Up Arrow] and [Down Arrow] until (S7) SPEED CALIB is displayed, press [Enter]
to highlight the current setting.
9. Press the [Up Arrow] and [Down Arrow] to enter the number of teeth on the engine’s flywheel
ring gear and press [Enter] to un-highlight the new setting.
10. Exit the S Menu by pressing [Menu].
NOTE: For mechanical engine throttling, see the PCBA SHUNTS section of this
manual for details.
Start/Stop Settings
There are five start/stop types in S35: SINGLE CONTACT, FLOATS, MOMENTARY, TRANSDUCER,
LOCAL PB (GREEN AND RED PUSHBUTTONS).
Single Contact Start/Stop:
The Single Contact Start/Stop is when a remote contact closes and remains closed for auto start, and
re-opens for auto stop.
(2) Float Start/Stop:
The (2) Float Start/Stop is when both float contacts are closed for auto start, and both float contacts are
open for auto stop.
Momentary Start/Stop:
The Momentary Start/Stop is when a contact closes momentarily for auto start, and a second contact
closes momentarily for auto stop.
Transducer Start/Stop:
A transducer is used for auto throttling. There are set points, allowing the operator to enter the
appropriate values.
Local Pushbutton Start/Stop:
The Local Pushbutton Start/Stop is when the local panel mounted green and red pushbuttons are used
for auto start/stop.
