Section 40 00-02-0716
2013-06-03 - 11 -
Use the following steps to select the correct transducer type:
1. Access the S numbers menu by pressing [Menu].
2. Use the [Up Arrow] and [Down Arrow] to scroll to the correct Entry Code (See Entry
Code Supplement for Entry Codes).
3. When the correct Entry Code is displayed, press [Enter] to access the S numbers menu.
NOTE: If the incorrect code is entered, “PASSWORD FAILURE” will appear on
the display. Press [Enter] and try again.
NOTE: S37 is the S-Number used for the transducer type. See the S number
section of this manual for details.
4. Press the [Up Arrow] and [Down Arrow] until (S37) XDUCER TYPE is displayed, press
[Enter] to highlight the current setting.
5. Press the [Up Arrow] and [Down Arrow] until the desired selection is displayed, press
[Enter] to un-highlight the new setting.
6. Exit the S Menu by pressing [Menu].
Tier 4 Emissions
The Tier 4 Emissions set up allows users of the EMS PRO to use it on an Interim Tier 4 engine. The
controller displays the SOOT level when the engine has been de-rated and/or when regeneration
(regen) is required to return to normal service on the front display.
NOTE: Please read and understand S84 (Request DPF Regen) found in the S-
number table.
• If the regen is selected, the ECU will perform a regen automatically.
• If a regen is requested, the controller will command the ECU to perform a
regen. This feature will only occur if ECU conditions allow.
• If Inhibit Regen is selected, no regen occurs.
To use the controller on a Tier 4 engine, follow the steps below:
1. Access the S Menu by pressing [Menu]
2. Press the [Up Arrow] and [Down Arrow] to scroll to the correct Entry Code (See Entry Code
Supplement for Entry Codes).
3. Press the [Up Arrow] and [Down Arrow] until (S82) TIER RATING is displayed in the menu
and press [Enter].
4. Press the [Up Arrow] and [Down Arrow] until TIER 4 is highlighted and press [Enter].
5. Press the [Up Arrow] and [Down Arrow] until (S83) TIER4 STATE and press [Enter].button.
The default value is set to AUTO. If you want the engine state to be in INHIBIT DPF REGEN
use the [Up Arrow] and [Down Arrow] to highlight the text and press [Enter].
6. To set the Diesel Particulate Filter (DPF) Regeneration follow the steps below:
NOTE: If all conditions for a regen to occur are not met, this request could be
ignored by the ECU.
a. Access the S Menu by pressing [Menu]
b. Press the [Up Arrow] and [Down Arrow] to scroll to the correct Entry Code (See Entry
Code Supplement for Entry Codes).
