Specifications
Operating Voltage: 8 VDC Minimum to 32 VDC Maximum. (Designed to work on 12 and 24 VDC
systems.)
Operating Temperature: -40
o
to 80°C (-40 to 176°F).
NOTE: Care should be taken when selecting the optional clear door when used in
applications involving direct sunlight exposure. Direct sunlight can cause premature
component failure by allowing the sealed enclosure temperature to exceed the rated
80
o
C/175
o
F.
Storage Temperature: -40° to 80°C (-40° to 176°F)
Environmental Sealing: IP66
NOTE: Meets IP66 when the door is closed and latched.
Relative Humidity: 95%RH @ 60°F (140°C)
Standby Current: 220mA @12VDC; 244mA @ 24 VDC
CAN Bus: SAE J1939 Compliant
Enclosure: Polycarbonate NEMA 4 (UL Certified)
Analog Inputs: 12 designated via program; sender/ground digital 4-20mA, 0-5 VDC
Digital Inputs: 8 high/low (Both Battery+ and ground are detected as active inputs. No signal is OFF).
Frequency: 1 optically isolated input for speed reference, magnetic pick-up, (2VAC-50VAC RMS)
Fuel Sender Input: 33 Ohm full, 240 Ohm empty
Analog Output: 1 optional; 4-20mA or .4 to 4.2VDC
Output pin assignment changes between two selections (modification to controller required to use these
ports - the software was written to accommodate future enhancements).
Digital Outputs: 3 FET B+ (rated at 1A), 9 digital outputs tied to relays
Relays: 1 SPDT and 8 SPST (5 Amp pilot relays)
NOTE: Maximum relay ground current limited to 23 amps.
User Interface: 8-button keypad, Graphical display, back lit.
Communications: RS485, RS232, CAN J1939, CAN 2.0B ports
Shipping Weight: 11 lb. (5kg.)
Shipping Dimensions (all models): 15 x 15 x 11 in. (381 x 381 x 279.4 mm)
Real-time Clock: 24hr Format
