Section 40 00-02-0716
2013-06-03 - 39 -
Installation
EMS PRO Mounting and Dimensions
The EMSPRO should be mounted in a location that is accessible to the operator. Use connection
harnesses to connect to the I/O and the engine. See the diagram below for connection instructions.
