Section 40 00-02-0716
2013-06-03 - 31 -
Inputs and Outputs
When wiring to the EMS PRO Controller, please refer to the schematic illustrating connector pin outs
for the following list of dedicated I/O:
Digital Inputs
1-Auto Position of Key Switch
2-Man Position of Key Switch
3-Single, Float, or Momentary Start Contact
4-Single, Float, or Momentary Stop Contact
5-Pump Low Oil Level Switch (i.e. L-129)
6-Un-Assigned (Reserved for Future Use)
7-Pump Housing High Temperature Switch (N.C. Opens on Fault).
8-Auxiliary 1 (Switch to Ground or B+)
Analog Inputs
1-Engine Temperature Sender (Murphy ES2T or VDO) Set in SENDER TYPES (S39) to Default
to Murphy Senders.
2-Engine Oil Pressure Sender (Murphy ES2P or VDO) Set in SENDER TYPES (S39) to Default
to Murphy Senders.
3-Engine Low Coolant Level (Switch to Ground, e.g. L-150)
4-Engine Low Oil Level (Switch to Ground, e.g. L-129)
5-Fuel Level Sender (Murphy ES2F)
6-Discharge Pressure Transducer (4-20mA)
7-Local Potentiometer Throttling (0-5 VDC) (Option)
8-Pump High Oil Temperature (Switch to Ground, e.g. 20P)
9-System Level Transducer (4-20mA)
10-Auxiliary 2 (Switch to Ground)
11-Auxiliary 3 (Switch to Ground)
12-Temperature Start/Stop, 0-5 VDC (Murphy AIR TEMP Model 12)
