Section 75 00-02-0522
04-06-11 - 9 -
Level 3 - Parameter Edit Access. Allows for viewing and parameter editing
but does not allow calibration of AC.
Level 4 - Calibration Access. Allows calibration of AC parameters.
Level 5 - kW Limit Edit and Config Select Access. Allows editing of kW
limits and various communication addresses.
2. Language - Allows selection of language used to display text.
a. English (Default)
b. Spanish
c. etc. (future expansion)
3. Driven Equipment Type - Allows selection of type of equipment that is driven by the
engine.
a. None (engine only, ignores all AC parameters)
b. AC Alternator (Genset) (Default)
4. Key Sensitivity Level - Determines how sensitive the touch pad keys are for your
application.
a. Low*
b. Normal (Default)
c. High
5. Default Screen - When the system is running this selects the screen that will show.
Event History
Warnings / Status
Engine / Gen Status
Meters
Nominal Meter
Splash Screen
Information
NOTE: * Newer versions of the controller/software will not have a “LOW”
sensitive selection.
6. Lamp Test - Tests LCD.
7. LCD Backlight - Turns the iGUARD display backlight off, unless an error condition
activates the common visual alarm.
a. Disabled
b. Enabled (Default)
8. Guard Beeper - Keypress indication and/or audible warning buzzer.
