Section 75 00-02-0522
04-06-11 - 12 -
22. Repeater #2 (set to Mimic as Default)
a. Set as Mimic Allows control capabilities without programming.
b. Set as Annunciator Allows viewing without control.
23. Winter/Summer Setpoint
a. Set Below Setpoint - If temperature is below setpoint, during start up,
automatic pre-heating begins.
b. Set Above Setpoint – If temperature is above setpoint, during start up,
pre-heating is bypassed.
Communication Parameters
1. J2 Protocol type - Selects the function that the selectable comm. port (on J2) will perform
a. RS-232 iGUARD config
b. RS-485 Modbus server
2. Modbus Server (SLAVE)” address - Sets the address of the Modbus server (247 is
default)
3. RS-485 Server (SLAVE) bit frame - Sets the number of start, data & stop bits for serial
communications via RS-485 Modbus
a. 10 bits N-8-1
b. 11 bits N-8-2
4. Server (SLAVE) Baud Rate - sets the number of start, data & stop bits for serial
communications via RS-485 Modbus
a. 9600
b. 19200
c. 38400 (Default)
5. RS-485 Client (MASTER)” bit frame - sets the number of start, data & stop bits for serial
communications via RS-485 Modbus
a. 10 bits N-8-1
b. 11 bits N-8-2
6. Client (MASTER)” Baud Rate – communication speed on the RS-485 Client (Master) port
a. 9600
b. 19200
c. 38400 (Default)
NOTE: Be aware that when using the iGUARD to drive PowerView analog
gages or the Remote I/O board, those devices only operate at 38400
baud.
Phase-out / Discontinued Product
