Relay Functions Display
All relay functions that are active will be displayed on the screen. If a relay has been assigned
a function that is currently active, then that relay number will appear to the left of the active
relay function name.
Relay designation is displayed in sequence. For the first remote relay board, the relay
designation will be assigned in sequence starting at 101 up to 124 (example, Relay 1 is
displayed as 101, Relay 2 is displayed as 102 , etc.).
For the second remote relay board, the relay designation starts at 201 up to 224 (example,
Relay 1 is displayed as 201, Relay 2 is displayed as 202, etc.).
