Murphy iGUARD - Menu Selection for Analog Inputs

Section 75 00-02-0522
04-06-11 - 31 -
Menu Selection for Analog Inputs
1
Disabled
15
VDO 7 Bar Oil Sender
2
4 - 20mA Oil Sender
16
VDO 5 Bar Oil Sender
3
0 - 5 VDC Oil Sender
17
Datcon Temp
4
4 - 20mA Temp Sender
18
Murphy Temp
5
0 - 5 VDC Temp Sender
19
VDO A Temp
6
4 - 20mA Fuel Sender
20
VDO B Temp
7
0 - 5 VDC Fuel Sender
21
BMI Temp
8
4 - 20mA Oil temperature
22
Datcon Fuel
9
0 - 5VDC Oil Temperature
23
Murphy Fuel
10
0 - 5VDC VDO Temp special (Optional
output board Required)
24
VDO Fuel
11
0 - 5VDC VDO Pressure special
(Optional output board Required)
25
Datcon Oil Temp
12
0 - 5VDC current
26
Murphy Oil Temp
13
Datcon Oil Sender
27
VDO A Oil Temp
14
Murphy Oil Sender
28
BMI Oil Temp
Clock Start/Stop Parameters
1. Press Enter to display the first start day and time screen. The default is OFF.
2. Press the Right and Left arrows to select a day of the week
3. Press the UP and DOWN arrows to select a time.
4. Press Enter to save.
