Murphy iGUARD User Manual

Section 75 00-02-0522
04-06-11 - 5 -
Programming the iGUARD from the Keypad
The iGUARD controller can be programmed in two separate ways. Most setup can be done
from the front panel. There are some parameters, such as changing passwords that require
the use of the iGCON software tool. The iGUARD programming menus can be accessed at
any time by pressing the left and right arrows at the same time. This will bring up the password
menu:
The factory defaults (and what they allow access to) for the various levels of password are:
Access Security - Allows input of 4-character security code.
 PASØ - No operational Access. It allows viewing of the data screens but
parameters cannot be edited.
 PAS1 - Operational Access. It allows Manual Start and Stop but parameters
cannot be edited.
 PAS2 - Parameter View Access. Allows for viewing of all parameters and
editing of the following parameter settings:
 Change Language
 Key Sensitivity Level
 Back Light On/Off
 Ack Maintenance Timers
 Enable Beeper
 Select Pressure Units
 Select Temperature Units
 Modify Date
 Edit Clock Start and Stop Timers
 PAS3 - Parameter Edit Access. Allows for viewing and parameter editing
but does not allow calibration of AC.
 PAS4 - Calibration Access. Allows calibration of the AC parameters.
 PAS5 - kW Limit Edit and Config Select Access. Allows editing of kW limits
and various communication addresses.
