Murphy iGUARD - Input - Output Test; Operation Mode; Repeater #1 (Set to MIMIC as Default)

Section 75 00-02-0522
04-06-11 - 11 -
time and date of iGUARD.
17. Input - Output Test - Shows the status of the analog inputs, digital inputs, and relay
outputs.
a. The analog input screen shows any change in the inputs. For example
if the resistance value of a resistive sender changes, the counts will
change.
i. Analog channel number
ii. Name/setup label
iii. Actual value
b. The digital input screen shows the status of the digital inputs.
i. Digital Input Number
ii. Name/setup label
iii. Made/open
c. Relay output status allows the forcing of any relay out. The screen
shows:
i. Relay output number
ii. Name/setup label
iii. State
NOTE: Analog values, digital input, and relay status may be read on these
screens at any time. The relays may only be forced in “Manual Mode”
while not running.
18. Reset Configuration - Allows user to force a complete reset to a known state and clears
all programming and customization.
19. Operation Mode
a. Manual, Auto, NFPA - If not in Auto, you’ll get Not-In-Auto alarm.
b. Manual, Auto No Warning - It disables the Not-In-Auto alarm.
c. Manual Mode Only - Can only be started from the front keypad.
20. Duplicate Senders - Allows ‘one only’ or more than one sender for engine pressures
and temperatures.
21. Repeater #1 (set to Mimic as Default)
a. Set as Mimic Allows control capabilities without programming.
b. Set as Annunciator Allows viewing without control.
Phase-out / Discontinued Product
