Section 75 00-02-0522
04-06-11 - 58 -
Specifications
Mounting (Cutout) Dimensions:
7.05 x 5.25 x 2.76 in. (179 x 133 x 70 mm).
Mounting Screws: 4, #6-32 screws and nitrile rubber o-ring are supplied to meet NEMA4
specs.
Case Material: Black Polycarbonate, textured finish, UV stabilized.
Connection: 600V rated multi-wire quick connect for DC and AC connections, suitable for wire
harnessing.
Power supply: Operates from any DC supply for 8-35VDC continuous. Brownout (5V) ride
through is 5 seconds and a total blackout (0V) ride through of 100 milliseconds.
Vibration/Survivability: 3g, 3 axis, frequency swept 10-1000 Hz.
Operating/Storage Temperature Range: –40/+185°F (–40/+85°C).
LCD Operating Range: –4/+176°F (–20/+80°C).
I/O’s: Designed to meet NFPA110/NFPA 99 plus offers additional inputs.
Performance Specifications: NFPA110, NFPA 99, SAE Load Dump Test.
Shipping Dimensions: 10 x 9 x 6 in. (254 x 229 x 152 mm).
Shipping Weight: 2 lb. (910 g.).
Standard Components
24 - Digital inputs 1 - RS232 port
7 - Analog inputs 1 - RS485 port
Inputs for up to 3-phases and neutral of AC voltage 1 - RS232/RS485 port
Inputs for 3 CT’s for current monitoring 1 - J1939 port
1 - Magnetic pickup input 1 - 64 x 128 pixel full graphic LCD with backlight
8 - 20A Form “C” relays 1 - 12 position keypad
Phase-out / Discontinued Product
Check Availability
