Section 75 00-02-0522
04-06-11 - 50 -
Installing the Mimic/Annunciator DM/A
DM/A Mimic/Annunciator Versions
This covers versions 1.26 and higher. The DM/A or Mimic/Annunciator is the repeater unit for
the iGUARD (Master) controller. The Mimic/Annunciator features the front bezel display which
includes the user interface board and Modbus device that communications with the iGUARD
(Master) controller and a wire cover. To operate the DM/A, power must be supplied to the J1
connector on the rear of the unit.
