Section 75 00-02-0522
04-06-11 - 27 -
7. Shutdown - Activated only by a fault shutdown.
8. Common Alarm - Any warning or shutdown condition will activate the relay.
9. Remote Alarm - Any alarm condition will actuate this output; can be de-energized by an
ACK or by a reset condition.
10. Air Damper N/De-energized - Relay operates when system goes into overspeed or if
emergency shutdown is active.
11. Not in Auto - Relay operates when system is not in auto mode - Self-clearing. .
12. Low Oil Pressure Warning- Relay operates when the engine oil pressure is below the
warning setpoint - self-clearing.
13. Low Oil Pressure Shutdown - Relay operates when the engine oil pressure is below the
warning setpoint - requires reset to clear.
14. Low Eng. Temp. - Relay operates when the low coolant temperature is below the setpoint
- Self-clearing. Coolant temperature is below the setpoint - Self-clearing.
15. High Eng. Temp. Warning - Relay operates when the engine coolant temperature is above
the warning setpoint - self-clearing.
16. High Eng. Temp. Shutdown - Relay operates when the engine coolant temperature is
above the shutdown setpoint - Requires Reset to clear.
17. Over-Speed - Relay operates when engine speed exceeds the setpoint - Requires Reset
to clear.
18. Over Frequency - Relay operates when AC frequency exceeds the setpoint - Requires
Reset to clear.
19. Under Speed - Relay operates when the engine RPM falls below the setpoint - self-
clearing.
20. Under Frequency - Relay operates when the AC frequency falls below the setpoint - self-
clearing.
21. Low Battery - Relay operates when steady state DC voltage falls below the setpoint - Self-
clearing.
22. Weak Battery - Relay operates when DC voltage during the crank cycle falls below the
setpoint - ACK or reset to clear.
23. High Battery - Relay operates when steady state DC voltage rises above the setpoint -
Self-clearing.
