In 3-phase applications apply:
phase A to terminal 1
phase B to terminal 2
phase C to terminal 3
neutral to terminal 1
In single phase applications apply:
phase A to terminal 1
phase B to terminal 2
neutral to terminal 4
In Center Tapped Delta applications, apply:
phase A to terminal 1
phase B to terminal 2
phase C to terminal 3
neutral to terminal 1
