User Manual of VT1000
- 5 -
* Harsh braking and harsh acceleration alarm
* Suddenly acceleration/brake alert
* Accident Alarm (optional)
* Two way communication (Listen & Speak, need speaker support) (optional)
* Oil leaking/Refuel Alarm (need fuel sensor support) (optional)
* Accident alarm (need crash sensor support) (optional)
* Support max 64G SD card store (optional)
* Photo with location & driving information log function (need camera support) (optional)
* Can equip with RFID kit for driver identification and auto Arm/Disarm functions
(movement/towed alert, ignition alert, auto cut off engine etc) (need RFID support) (optional)
* Analog input for Temperature & Fuel sensor detecting/monitoring, support max 4 fuel sensor
manage (optional)
4. Specifications
Items Specifications
Dimension 110*80*30mm
Weight 180g
Input voltage DC 9V~35V/1.5A
Back-up Battery 850mAh
Velocity 515 meters/second (1000 knots) max
Operating Temperature -20°C~75°C
Humidity 5%~95% Non-condensing
Altitude Limit 18,000 meters (60,000 feet) max
LED 2 LED lights to show GPS, GSM status
Button 1 SOS and 1 power on/off
Microphone Default
Cold start 42sec., average
Hot Start 1 sec., average
GSM Frequency GSM 850/900/1800/1900MHz or GSM 900/1800/1900 MHz
GPS Chip Latest GPS SIRF-Star III Chipset
GPS Sensitivity -158dB
Positioning Accuracy 10meters, 2D RMS
GPS Frequency L1, 1575.42 MHz
C/A Code 1.023 MHz chip rate
Channels 20 channel all-in-view tracking
Velocity Accuracy 0.1m/s
Time Accuracy 1 us synchronized to GPS time
Default datum WGS-84
Reacquisition 0.1 sec., average
I/O 5 Input 5 Output 1 Camera Port
4 Analog Input 1 RS232 Port 1 MIC& Speaker Port
1 USB Port 1 SD Card Slot
