MUTOH VJ-2638 - Head Alignment

Before using VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
124 3.5 Test print
3.5.6 Head alignment
You can print out the adjustment pattern in this menu to check the misalignment of the print head, and
then adjust it.
Adjustment methods for this printer are as follows.
NOTE
• Print quality may improve by head alignment in the following situations:
• Print quality is poor when using the uni-direction print mode
• Print quality does not improve even after performing print quality adjustment
3.6 Print quality adjustment
• After you have performed head alignment, make sure you perform print quality adjustment.
There may be misalignment caused by head alignment.
3.6 Print quality adjustment
• When changing the print mode after performing standard head alignment, make sure you adjust
print head.
• Since all print modes are adjusted at once after performing Custom head adjustment, head
adjustment is not required even after changing the print mode.
• When specifying a print mode for RIP software, etc, that is different from the mode set in the user
type setting, perform Custom head adjustment and check all patterns (A to F), and then adjust any
patterns that are misaligned beforehand.
Adjustment
method
Description Reference
Standard Adjustment is performed only for the print mode set by the
current User Type.
3.5.6.1 Standard head
alignment
Custom Adjustment is performed for all print modes that can be set
by the current User Type.
3.5.6.2 Custom head
alignment
