VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL Before using
3.6 Print quality adjustment 147
7. Press the [Enter] key on Operation panel.
• Determines the setting.
• "Pattern*2: 11" is displayed next.
8. For Head 2, check the print results on both sides and center of the media and select the number that
looks most aligned between 1 and 21.
9. Press the [+] key or [-] key on Operation panel to enter the number that you selected in Step 8.
123456789101112131415161718192021
2
To Next Page
