Before using VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
150 3.6 Print quality adjustment
• An micro adjust print pattern is printed for both Head 1 and Head 2.
(VJ-2638/1638X starts printing after warming up is complete.)
• For the micro adjustment pattern, the same patterns will be printed on both sides and center of
the media.
4. For Head 1, check the print results on both sides and center of the media and select the number that
looks most aligned between 1 and 7.
• 6 is selected in the next printing sample.
NOTE
• 4 represents the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
ᵏ
ᵐ
ᵐᵑᵒᵓᵔᵕ
ᵏ
ᵏ
ᵐᵑᵒᵓᵔᵕ
Pattern for Head 1
Pattern for Head 2
Pattern name
Current Print Mode
Q3/Q4/G1/G2
B
Good Not goodNot good
