MUTOH VJ-2638 - Page 210

Handling the printer VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
210 4.4 Operating from Operation panel
4. Place a razor blade on Media cut groove on Media guide, and cut the roll media.
CAUTION
• Pay attention to the following points when cutting roll media.
Mishandling Razor blade may cause a cut on your finger or hand.
• When you hold media, do not place your finger on Media cut groove.
• Move Razor blade slowly along Media cut groove.
• The procedure for cutting the roll media is complete.
NOTE
• When loading the new roll media, cut the front edge of the media if it is not straight.
No. Name
1 Media guide
2 Media cut groove
3 Razor blade
1
2
3
