MUTOH VJ-2638 - Page 91

VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL Before using
3.4 Loading media 91
4. Set the roll media to Media feed slot.
NOTE
• If the end of the roll media is not wound tightly, wind it tightly again, and then load it.
5. Pull the roll media out about 1 m from the front Media feed slot which is located inside of Front
cover.
No. Name
1 Roll media
2Media feed slot
No. Name
1 Roll media
2Media feed slot
1
2
1
2
