VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL Before using
3.4 Loading media 93
7. Make sure that the edges of the media is appropriately pressed by Pressurizing rollers.
• When the media is set as shown in the following figure X, follow the procedure to adjust the
position of the roll media.
If the media is set as shown in the following figure X, the media may be misaligned or creased
during printing.
<For VJ-2638/1638X>
No. Name
1 Roll media
2 Pressurizing rollers
No. Name
1 Roll media
2 Pressurizing rollers
1
2
1
2
1
5mm
5mm
5mm
1
222
11
