Suspension and wheels
F
- 77 -
Evaluate the wear condition of the crown wheel. If it is
badly worn, effectuate a substitution with a new part
proceeding as described.
Extract the 5 spring drives (2) from the gear flange sup-
port (3) and assess its condition.
If the spring drives are worn, replace with new ones.
Check that the coupling bushes of the gear flange sup-
port (1) and the driving flange (2) do not show any
signs of excessive or uneven wear.
If the bushes are excessively worn, replace the entire
set of flanges.
3
2
1
2
